Extra Info: There is no upper limit of material hardness for a Gentle Grip Clamp as they do NOT grip by "Teeth" like a conventional vertical clamp. The Camlok LJ & TSB Clamps grip by friction.
Suitable for use on Hardox Plate 400 & 500 Brinell
Designed for use with plate cut on the water-jet cutter, but obviously not completely submerged.
WARNING: The non marking LJ clamp should not be subjected to any side loading if possible. Any side loading will detract from the load carrying grip with the risk of slipping. We still show the 15degree tolerance but I would strongly recommend that the clamp is used with no side loading. The LJ clamp should not be used on two leg slings
